WE DESIGN , DEVELOP ,AND CREAT

  • ENERGY SAVING SYSTEM

  • ENTERPRISE APPLICATION

  • PAYMENT SOLUTION

Services

What we can help you with:

  • Optimize performance of enterprise-level systems (up to 300x improvement).
  • Cluster of service in complex systems using Java EE.
  • Build applications for mobile phones based on IPhine or Android.
  • Work with audio- and video-streaming for both mobile and desktop platforms.

We Design

HTML5 Power

CSS3 Awesomeness

jQuery / Tapestray Magic

We Create

Web Apps

Android / IOS Apps

J2EE application server

WE OFFER

Stability

Huge Capacity

Extendable Cluster


Products

These below are our products.
Take a look at our most recent projects.

Product Details

    Taxi Dispatch system

    Taxi Dispatch
    Categories : Taxi Dispatch
    It can be located according to passengers’ GPS, and automatically arrange the nearest and closest empty car.
    While the 4,000 vehicles are running at the same time, 60 cars can be sent per second.
    The history record of asking for a taxi:It has a complete record of each passenger’s address about getting on or off the bus and the number of service personnel, and provide the most complete record management system.
    There has a reception desk of 3000 taxis, and just needs to arrange 25% telephonists for receiving telephone and sending the car.

    Abstract

    It costs the taxi driver 10 hours to drive a day, of which hunting for passengers in the streets without anybody in the taxi for more than 7 hours, and that is not only a waste of gasoline but also causing the problems of air and traffic. But in order to earn the basic necessities of life, the drivers apart from waiting for the passengers in front of the station for a long line, or spending more time looking for the passengers who are waving their hands on the roadside, so the driving safety is affected by the long driving time.
    Nowadays the smart phones are widely used, and the passengers just can immediately arrange a taxi when click the action APP. So there is no need that waiting for the telephonist to arrange. That can not only improve the efficiency, but also reduce the unfairness which is caused by the human relations. The radio call of traditional car dealers is that the reception desk informed drivers the dealer task, and then the drivers replied the willingness of carrying the passenger. The victory comes from the first, so the strong wave devices are installed in some taxis, overshadowing the nearest vehicles’ response. In addition, the reception desk may deliver the task to the familiar drivers because of the human feelings.

    System features



    1. Dispatch vehicle automatically:It can be located according to passengers’ GPS, and automatically arrange the nearest and closest empty car.
    2. The way of asking for a taxi:APP can be used for automatically sending a car or making a phonecall for asking for the telephonist’s help to arrange
    3. Save time:There is no the phenomenon that the passengers exposed in the sun and rain of the roadside and waited in vain because they cannot call the car, and also will not take two passengers so that A passenger is carried firstly to destination, and then let the B passenger wait in the original place in vain due to the drivers scramble for the passengers (A, B).
    4. Simple calculation:It can calculate the approximate number of kilometers that from starting point to the destination and the fare for the guests to refer.
    5. Avoid detours and lost:It can prevent the drivers going fruther distance, or encountering less familiar areas. The driver can simply carry the guests to their destinations through navigation.
    6. A wide range of taxi services:Generally ask for the car (while asking for, and dispatch the car) and appoint to ask for car (the car can be sent according to the guests’ requirements about the time and place)
    7. The category of vehicle type:It can specify the vehicle model(car, SUV) or designate service driver
    8. The history record of asking for a taxi:It has a complete record of each passenger’s address about getting on or off the bus and the number of service personnel, and provide the most complete record management system.
    9. Considerate warning:After calling the car the successfully (either call up or use APP), and inform passengers about the taxi data transfers and drivers special line.
    10. SECDOR:Drivers get into the same area (can set the range), and can automaticaly be informed through dispatching the identification tag, then waiting for the passengers in this area call the car and dispatching the car according to the sequence.
    11. The speed of dispatching a car:While the 4,000 vehicles are running at the same time, 60 cars can be sent per second.
    12. Shift system:After the car dealers buy the car, the personnels can be arranged for shifting drive for the same car, the driver of each period can login in proper sequence and automatically update current drivers data and condition data.
    13. Location mode:The maps can be directly downloaded and installed on the phone, and there is no need to open the satellite positioning so as to save the Internet transmission charges.
    14. Adverse records’s drivers:The service can be set to suspend for those who are late to pay the membership dues, or are complained by the guest, or refuse to be sent by the system. (The reception desk can set the system downtime of bad records drivers for several hours, or to be permanently suspended

    Cost effecifient



    If a reception desk has 3,000 taxis, 64 telephonists should be arranged for answering the phone and sending a car. So when the passengers call the reception desk each time, they should wait the telephonists understanding the address, then contact the dealers drivers and wait for the drivers’ response, then inform the passengers whether it is successful to sent the car or not.
    If use this system:
    There has a reception desk of 3000 taxis, and just needs to arrange 16 telephonists for receiving telephone and sending the car. Passengers call the reception desk, just waiting for the telephonist check empty cars which have the identification tag in the system. When dispatched successfully, then can instantly inform the driver’s data and vehicle condition to the passengers. Or the passenger directly click and send a car through penetrating the APP, and the system will automatically send the car and notify passengers’ position to the driver.
    For more detailed information, please contact.

    Internet Power Box

    Automation & Security
    Name :Internet Power Box
    APP Support  :  Android >2.3 , IOS
    APP name: Etouch (Google play , App strore)
    User management : By manger APP; QR Code

    Vector Net switch , Remote Power Switch, is the ideal solution for remote reboot and many other remote power control applications. Vector Net switch series has 4 power outlets which can be independently controlled using a web app. Vector Net switch use DHCP and auto register to server . User just scan the QR code, then he can use the device.

    Abstract

    NS20-4P is a TCP/IP contorl box which is required to work with smartphone APP. Let you achieve automation easily, Power control, Home appliance control, switch control or Security..etc. 1. Power control: Four power control port (Click on the specification page View Details)
    2. Dimming control: adjust the lamp brightness or LED lights (Click on the specification page to view details)
    3. The door lock control: electronic door locks, such as cut the power to open electric lock or supply power to open electic locks.
    The NS20-4P installation is very simple. Only need to connect the power plugs to the socket of NS20-4P. NS20-4P supports network DHCP. Plug and play.

    Application

    1.remote power on/off Machine.
    2.Reboot machine /IT equipment
    3.Schedule reboot.
    4. Auto Cut the Internet connection.
    5.Irrigation pumping motor
    6.Fish ponds oxygen supply

    Specifcation


    NS20-4P
    1) 4 Port Power control out put.  Plug for EU and US type both.
    2) Overload protection : 10A.  When NS20-4P got the electricity over 10A, cut the power automatically.
    3) Size / weight :  15.8 * 10.5 * 3.9 cm , 0.4Kg
    4) Power: Input AC100-240V
    5) Operation Temperature : 0 ~ 65° C
    6) Operation Humidity : 5 ~ 95%RH
    7) Storage Temperature : -20 ~ 85°
    8) CE , FCC approval

    Android Taxi driver device

    Taxi Dispatch
    Date : November 2013
    Client : Company SA
    Categories : Web Design
    Website : www.example.com

    The Challenge

    DriverDorid is design for driver to communication with Taxi cental . It is designed to meet the needs of today’s dispatching and transport businesses, the DriverDoid  is an affordable and easy to use mobile data terminal designed for efficient driver and dispatch operation. With a compact layout, fixed function keys and simple, 7"~9" touchscreen display,  flexible wireless connectivity options, the DriverDroid  is designed for the Taxi industry.

    The latest Mobile Data Terminal for our Taxi Dispatch Solutions, the DriverDroid  offers standard features like 12 channel GPS, and  an enhanced graphical user interface for simple navigation and ease of use.

    DriverDroid use its internal map database , so it did not need to check the map form Google map  , and this will save the data communication cost.

    DriverDorid was design for Android smartphone , and recommand for 7" touch screen ,

    We design Driver Dorid for .

    This capability lowers ongoing maintenance costs because customers no longer have to bring in their vehicles for servicing each time a new version of software is released.

    Flexibility in wireless modules ensures that the Vector 800™ has the option of supporting either private or public networks. For private radio networks, the Vector 800™ uses a high performance built-in Digital Signal Processor (DSP) that provides data rates of up to 9600bps over private mobile radio. For cellular public data networks, the Vector 800™ interfaces with GSM/GPRS or CDMA modems.

    The Solution

    Lorem ipsum dolor sit amet, consectetur adipiscing elit.Nam sapien risus, blandit at fringilla ac, varius sed dolor.Donec augue lacus, vulputate sed consectetur facilisis,interdum pharetra ligula. Nulla suscipit erat nibh, utporttitor nisl dapibus eu.

    The Result

    Lorem ipsum dolor sit amet, consectetur adipiscing elit.Nam sapien risus, blandit at fringilla ac, varius sed dolor.Donec augue lacus, vulputate sed consectetur facilisis,interdum pharetra ligula. Nulla suscipit erat nibh, utporttitor nisl dapibus eu.

    VT800 android Touch Panel phone

    Payment Terminal
    Operation : System Android 4.1.1
    Screen : 7 inch G+G 5 Point Capacitive Touch Screen
    Resolution: 1024x600 Pixel
    CPU : RK3066 Dual Core A9 1.6Ghz
    GPU: Quad Core,Mali-400 MP,Support OPENGL ES 2.0
    RAM : 1GB DDR3
    Nand Flash: 8GBa
    Webcam: 0.3MP Front Camera
    Wireless: Wifi 802.11 b/g/n
    Bluetooth N/A
    HDMI: Support,1080P
    GPS: N/A
    G-sensor: Support
    Power:
    Power AC: Adapter Input 100-240V 0.3A 50/60Hz output 15V-2A
    Video : AVI, MP4, FLV, 3GP, MKV, WMV etc.
    Audio : MP3,WMA,WAV,APE,FLAC,AAC,OGG etc.
    Picture JPG/BMP/PNG/GIF.
    Card reader : RFID Mifare S50
    3G Version : WCDMA module (OPTIONAL)
    RJ45 VERSION : VOIP PHONE CALL
    VOIP SPECIFICATION :
    CODEC : G729 , GSM , ALAW , ULAW

    Abstract

    VT800 Android mini KIOSK is a new model of public telephone, in addition to the function of traditional public telephone, VT800 Android mini KIOSK can provide the function of payment.  It may take place ATM function at some countries or rural  areas.

    VT800 Android mini KIOSK  adapts Android 4.1 up working system.  It also increases another function via new innovative APP.

    VT800 Android mini KIOSK provides beautiful interface design and sensitive touch PAD.  It may provide with more wonderful public service of information via a good use instruction and verbal express.

    VT800 Android mini KIOSK also provide online purchase or payment service in addition to the RFID card reader or magnetic card reader.





    Function

    Now we provide 3G version which has the function of dialing the telephone and transferring the message and the RJ45 internet version has the telephone function by using VOIP system mode.

    Except telephone function, another suitable functions are as follows, but the most functions should be adjusted according to the local telephone service and practical usage.

    Top up prepaid function:  It makes the card revolve the use at the request of the client.  However the user can top up the money when it is used out.

    Account management: The function can let the user check the using record.

    We provide the card management server something like bank account.  It has function of recording and checking the transaction.  All transaction records will be transferred to the server thru internet. VT800 payment terminal will download the blacklist every day and transfer the transaction record.

    Application

    As regards the top up payment of the mobile phone air time: There are some telephone companies in many countries using prepaid card, it is often very difficult to look up the top up payment retailer.  This function may let the user top up via VT800.On software, we can make it according to the local circumstance and at request of the client.

    here are two ways of top up payment.

    1. It tops up by VT800 payment terminal: Every VT800 payment terminal contains top up prepaid card which has the function of toping up the assigned telephone directly.  After VT800 payment terminal deducts the card amount directly via the card, VT800 payment terminal issues USSD number to top up the card directly.
    2. The server substitutes VT800 payment terminal toping up the payment: VT800 payment terminal requests the server to handle the transaction.  The server issues USSD code via gateway or GSM modem and then payment terminal will deduct it if it is okayed.

    The money amount will be transferred to the other user: It can transfer directly from the card holder’s paying amount to another user’s card amount.  It likes the transfer system of bank account.   All the transaction should be thru the high security of multiple check online internet and server.

    To pay the water fee by the prepaid card:  The user may pay the water and gas fee by VT800 payment terminal.

    The above-mentioned service frontend APP and payment gateway software are to be made subject to the local service provider with their software Protocol and special arrangement.

    Online purchase: The user may use VT800 Android mini KIOSK to buy the products provided by the system.  The system may deliver the goods as per registered address.

    PSTN payphone

    Payment Terminal
    Name : VT700G PSTN Payphone

    Support Remote manager System (RMS):

    1.   Fault alarm

    2.   Call Detail Record (CDR)

    3.   Parameter setting

    4.   Rate table setting

    5.   Revenue analysis

    ABSTRACT

    Scenario could be modifed to Co-work with your System:

    1.   Hook off , auto-dial access number to connect server

    2.   Hot line programmable

    3.   DTMF tone receiver

    4.   support 12K, 16k, tone reciever, ... signal recognize

    5.   No battery inside

    6.   Real time clock



    General Functions:

    1.   Reverse \12khz \16khz \ 50Hz \ A, B,or C Tone \ Voice detection \ meter signal selection

    2.   1000 sets area call defined

    3.   Follow on \ Redial

    4.   Free call \ Barred call programmable

    5.   Local \ STD \ IDD enable or disable

    6.   Auto-tariff by input city code

    7.   Discount time programmable

    8.   Volume control

    9.   Multi-language selection

    10. Program by keypad \ cable from compute

    Specification

    Model

    Description



    VT700G-3

    ‧Housing: Made by Metal , thickness of Metal : 1.6mm

    ‧Dimension : 33cm *:20CM *7.5CM / 6Kgs

    ‧Power : PSTN Line power only

    ‧Temperature -10C~55C

    ‧16 digits LCD Multi-Display

    ‧CE approval

    The Application

    1.  School

    2.  Department store

    3.  Jail

    4.  Hospital

    5.  Transportation stations

    Support Remote manager System (RMS):

    1.   Fault alarm

    2.   Call Detail Record (CDR)

    3.   Parameter setting

    4.   Rate table setting

    5.   Revenue analysis

    Door opener (by your smartphone APP)

    Automation & Security
    Name :  Garage door opener
    APP Support  :  Android >2.3 , IOS
    APP name: Etouch (Google play , App strore)
    User management : By manger APP; QR Code

    Via Etouch , the manager can add/ delet any user by his App. He can authorize a new user by send him a QR code. And if any member quit , he just delete his name from the user list.
    User can use this APP by 3G/wifi.

    Abstract

    Now you could use iPhone or Android smartphone to contorl the rolling door or garage door.

    You just need to add our NS20 sereis TCP/IP controller with your Door opener. The NS20 TCP/IP control box is a small device which received the command from your phone and send the trigger singal to your rolling door motor or control buttons.

    It is very easy to insall. Just Plug the power , internet line and the control line to the NS20 control box.

    Compatable with original IR controller.  Smart phone and IR controller could work at the same time.

    The Solution

    It is troublesome to copy the key, when the remote control device is missing, the younger brother moves to live together, it also needs a remote control device.  When the remote control device is out of order, it needs to renew one.  The resident in the community let’s say 100 houses, it needs 300 or 400 pieces of remote control device.  It is costly.  There is no limit to the number of users for usage.  It helps save at least really 50% of cost.  It is worthwhile.

    No distance Limitted

    No matter where you are, if the mobile phone is on line you may open the door. You may not wait for the goods carrier to send the goods later and sit at door for waiting. Upon the arrival of the goods carrier at your house, he just gives you a call, you may help him open the door immediately. It saves your precious time.



     Application

    Our product can apply to various electrical operation doors, workshop sliding doors, electric key for apartment, speedy roller shutters, traditional roller shutters and gates at the parking terminal or yards.

    One handling for many doors

    To a lot of keys, remote control devices, it takes a precious time to look for right exact key to open the door our App can operate and handle many doors, one, two, five or ten, we only use one mobile phone to cope with it. There is no trouble for taking care management of keys and remote control devices.

    Notification

    Whatever you use the mobile phone to open the door, the key or remote control device to open the door. When the door is opened by the theft once the door is open, the App will sense it. You may check the record of the user at any time. It lets the house secure.

    User managerment

    Apply to IOS and Android system, we innovated a set of safe privy calculation on the basis of QR code system, we assure it will not be disclosed by QR code management of increasing and deleting the users. To set up the apparatus, it can be completed only by the scan of QR code. To intend to increase the new user you just scan the QR code and the resident leaves, you delete it directly from the mobile phone. It is safe and easy.

    Mifare S50 payment card

    Payment Terminal
    Chip: Mifare 1K S50 (NXP original)
    Function: Read/write (protected by password))
    Memory size: 1K-Byte EEPROM (16 sectors)
    Frequency: 13.56MHz
    RF Protocol: ISO14443A

    Abstract

    Mifare 1K is accepted as the Market-leading technology ISO14443A. Mifare 1K smart card is a great solution for E-ticket, payment, hotels, access control and time attendance systems. .

    我們所採用的付費系統採用的是這一種卡片, 並且採用特殊的編碼加密方式, 更加提升了卡片的安全性。



    The Solution

    Mifare 1K S50 smart card is widely used in the secure RFID applications. The 1KByte of EEPROM is configured into 16sectors, so one single card can be applied for multi- applications.

    Key features
    Dimensions: 86 x 54mm
    Thickness: 0.84mm
    Material: PVC, PET
    Surface: lamination (gloss/mate)
    Working frequency: 13.56MHz
    Reading distance: 6cm
    Data storage time: minimum 10 years
    Operating temperature: -20 to +60°C
    Stockage temperature: -20 to +65°C
    Package: 200pcs per Inner Box; 4000pcs per Carton, each Carton gross weight is 28kgs
    Printing options
    Full color offset printing
    Silk-screen printing
    Silver/Gold silk-screen printing background​

    Application

    E-ticket
    Payment
    Hotel key lock
    Access control
    Time attendance system

    optional printing:

    • Full color offset printing
    • Silk-screen printing
    • Silver/Gold silk-screen printing background
    • Personalization

    option for standard cards:

    • Magnetic stripe: 300oe, 2750oe, 4000oe
    • Numbering
    • Barcode printing
    • Signature panel
    • Embossing
    • Encoding (according agreement)

    Android Video/Audio Intercom system

    Automation & Security
    Name : Android Video/Audio Intercom System
    Application :

    ATM EMERGENCY INTERCOM

    ELEVATOR EMERGENCY  INTERCOM

    HOSPITAL ICU INTERCOM

    PRISON INTERCOM

    TOWN COMMUNITY  INTERCOM

    The Abstract

    In View of many traditional apartment, most of their audio talky system are old or non-operational. The set up of the traditional audio talky system is to be matched with each individual resident’s tele wire line system.If you do not maintain and control it well, it will suffer form fire hazard and any other safely cause.

    Our company innovated the gate video and/or audio talky intercom system which develops the internet connection method without needing to set up the complicated  wire line system, it just apply android smart hand phone or tablet computer and set up one set of multi-purpose digital video and/or audio talky intercom.



    The Function

    FUNCTION : GATE DEVICE

    • THE VISITOR CAN LOOK FOR THE RESIDENT THE INTERCOM IS ONE WAY DEVISE FROM THE RESIDENT TO THE VISITOR-
    • THE VISITOR CNA LOOK FOR THE MANAGER-
    • TO APPLY THE FUNCTION OF INTERNET AUTOMATE OFF SENSE SYSTEM.IT IS EASY TO CHECK IT.

    FUNCTION : INDOOR DEVICE

    • May talk with the manger-
    • may talk with gate intercom-
    • door to door ,two ways of inward and outward video and/or audio intercom.-
    • may set up one way of intercom-
    • if the visitor can not find the resident, he can contact the resident’s hand phone directly.
    • the resident can record the visitor’s information
    • apply jpg system photo-
    • may apply mp3 system to use music voice as ring bell call-
    • may apply the automate sensor function when the internet is off. it is easy to check the system

    The Features

    • every body can handle it
    • Inter face, concise multi-purpose combined to one system
    • apply android system :it is easy to get it
    • No need to fit the tele- wire line
    • No need to set up the complicated tele-wire system
    • Use internet communicating method
    • No wire-line system,the rate of breakdown is the lowest.
    • even it breaks down,it will not affect the function of any other users

    Adjustment of illumination and safety alarm system

    ZigBee Home automation
    Name : Adjustment of illumination and safety alarm system

    Solution : white balance

                   Safety Alarm

    The Abstract

    Illumination equipment  to combine with digital micro-wave sensor. Our product can sense the person and/or object passing the area. It depends on the actual condition in need to set up the controlled area. It can control and adjust automatically .The most sufficient, illumination and energy saving .

    The Application

    Parking garage area lighting system

    The office lighting system

    Product/

    Specification

    NS30-

    Zigbee Doppler Sensor

    Input Power

    110-240V AC

    Output

    3.3V DC

    5V DC

    Application

    Parking、Office

    Plug Type

    US Specification

    EU Specification

    Internet Mode

    2.4GHz(IEEE 802.15.4 and Zigbee) Zigbee @2007

    DO



    DI

    1

    Operating Temperature

    0-50 ℃

    Operating Humidity

    5-95RH

    Dimensions(mm)

    115*90*40

    Weight(g)



    Inter Compatibility

    IOS. Android

    Person limit

    None

    Bandwidth

    2.4~2.4835GHz

    Communication Distance

    Over 53meter (Open Area 50Meter,Indoor 10Meter,After Wall 5Meter)

    Power Consumption

     CPU 2.1W (1~0.35W)

    Detection Method

    Moving Sensor

    Detection Area/

    Detection Distance

    0.3~10M

    Detection Point of View

    Horizontal 72 degrees

    Vertical  36 degrees

    Mounting height of Device

    150cm(Horizontal)

    Initialize time

    Over 4 Second

    The Features

    Escalating Adjustable Illumination

        In order to avoid lighting on and off source, this system will extend the life span of light bulb lamp.We adopt the function of gradually escalating adjustment for illumination without the feeling of sudden on and off. The user will not obviously feel the work of system in the active area.

    Detecting the activity of human body to the best energy saving.

    There are some areas where the persons are a few activities,such as sidewalk and pantry room.The sensible body enters areas of activity, the device automatically adjust the illumination of whole areas.

    Automatic making up the sun light

         During the time of dusk or early in the morning,the sun light is weak, it will automatically adjust the level of illumination.It adjusts the illumination gradually in a free feeling condition without affecting the office work atmosphere and reading.It also saves the cost efficiently.

    Smart adjustment of illumination

       In the area of insufficient illumination,it can activate the strong light device (Such as LVD electrode less fluorescent lamp)

    SAFETY ALARM

     The manual operation or automatic time shift is the function of safety alarm.

    For safety alarm function which can sense and detect the human body and /or object movement and report it automatically.

    USSD Topup machine

    Payment Terminal
    Name : USSD Topup machine

    ABSTRACT

    What is USSD?

    USSD (Unstructured Supplementary Service Data) is a protocol used by GSM system. USSD is used for the prepaid mobile credit service. Recharge the credit to mobile account…ect.

    Introduce:

    Having the GUS01 GSM USSD recharge machine, you could offer the USSD recharge service. Customers go to the GUS01 , key in the phone number he likes to recharge and insert the coins. The GUS01 will recharge the credit to your cell phone number. Start to run the USSD recharge business now.

    Features:

    1. 3 different GSM SIM card support : According the phone number you like to recharge, auto-switch the GSM SIM card to recharge the credit

    2. Voice indication: support to play the voice indication to guide the users operate the GUS01.

    3. LCD display : 4 lines LCD display with backlight. Easy to operate.

    4. Coin acceptor: detect the coin diameter, material and thickness to recognize the coins.

    5. Big coin box volume

    6. Alarm : when the SIM card credit in machine is ran out of credit. The GUS01 will send the SMS to alarm

    7. Printer : supports to print the receipt.

    Specification :

    Power

    AC100-240V, 50/60Hz

    Metal housing

    1.6mm metal housing

    LCD Display

    16 digits x 4 lines with back light

    Capacity of Coin Box

    1.3 liter

    Keypad Life

    >500,000

    GSM frequency

    GSM : 850MHz/1900MHz/ 900MHz/1800MHz

    Dimensions

    146.5mm X 276 mm X 420 mm

    Weight

    12 KGS

    Temperature

    -5°C to +60°C

    Humidity

    0% to 90% Non-Condensing

    VT700 GV VOIP Payphone

    Payment Terminal
    Name : VT700GV VOIP Payphone


    ABSTRACT

    The Outdoor calling-card telephone.

    Calling card system provide cheaper call rate to end user.

    In order to keep high security, most calling card has a long

    digitals PIN numbers. The longer PIN numbers, the more

    security the system has. But On the other hand, the long

    digitals PIN also raise up the failure rate because end user’s wrong operation.

    Mostly end-user hang up the calls when they press any

    wrong number, even the IVR system provide a error flow to

    fix this problem. So a lot wrong operation, occupy the lines.

    Emergency Solution

    Hotlin phone : user pick up the handset . Phone will dial to emergency number automatically.

    AD phone :  User press the keypad to choose hotline number.


    Calling Card Solution

    User pick up the handset and Key in the PIN number to make calls.  Tariff is contolled by management system.

    The Specification

    Model

    Description

    VT700GV-4

    Housing:Made by Metal , thickness of Metal : 1.6mm

    Power : adaptor input 100-240AC output:12V 1A

    ‧Temperature -10C~55C

    LCD: 128*64 dot Matrix with Backlit

    ‧CE approval

    VOIP Specifications:

    1.     Easy Interface to ADSL/Cable Modem or leased line equipment.

    2.     Support SIP v1 (RFC2543), v2 (RFC3261)

    3.     Behind NAT Router or IP sharing Device.

    4.     DTMF support : SIP info, RFC2388, Out -band DTMF, In-Band DTMF.

    5.     Configuration : Web browser, Console/Telnet, IVR/Keypad, Auto-provision.

    6.     Firmware Upgrade : TFTP/ Console/ Http/ Auto-Proision

    7.     Support Fix IP/DHCP/PPPoE

    8.     Codec- G.711 A/u-Law, G.723.1, G.729A, G729

    Application

    1.School

    2.Department store

    3.Jail

    4.Hospital

    5.Transprotation stations

    Video Intercom and baby cam

    Automation & Security
    Name : Video Intercom and baby cam

    ABSTRACT

    Vector VOIP Video Intercom based on VOIP technology and support most codec .A full function PBX serve all Video connection , and user don’t need to have any complex setting.   Video intercom  Systems may be installed outside or inside. In addition to clear sound, video intercoms offer sharp colour images. The advantage of a video intercom is that users can see potential visitors and anyone else with them.Network-enabled VoIP paging and intercom stations connect stores, warehouses, administration and customer services in a single, scalable audio communications network. You can download our free Video APP “Baby Cam”, you’ll find it is so easily to install and use the app to monitor or chat with the other party.

    Features

    Android and IOS
    Wifi and 3G Mode
    Download Free App "BabeCam"
    Customized Video intercom

    Application

    Retail security, SIP enabled paging

    Shopping centers

    Customer help kiosks

    Promotional information

    Convenience stores

    POS help and remote monitor

    Inter-store VoIP communications

    Zigbee Opener

    ZigBee Home automation
    • Name :  NS30-Zigbee  door opener
    • APP Support  :  Android >2.3 , IOS
    • APP name: Etouch (Google play , App strore)
    • User management : By manger APP; QR Code
    • Via Etouch , the manager can add/ delet any user by his App. He can authorize a new user by send him a QR code. And if any member quit , he just delete his name from the user list.
    • User can use this APP by 3G/wifi.

    The ABSTRACT

    • Now you could use iPhone or Android smartphone to contorl the rolling door or garage door.

      You just need to add our NS30 sereis Zigbee door r controller with your Door opener. The NS30 zigbee control box is a small device which received the command from your phone and send the trigger singal to your rolling door motor or control buttons.

      It is very easy to insall. Just Plug the power , internet line and the control line to the NS30 control box.

      Compatable with original IR controller.  Smart phone and IR controller could work at the same time.

    The Solution

    It is troublesome to copy the key, when the remote control device is missing, the younger brother moves to live together, it also needs a remote control device.  When the remote control device is out of order, it needs to renew one.  The resident in the community let’s say 100 houses, it needs 300 or 400 pieces of remote control device.  It is costly.  There is no limit to the number of users for usage.  It helps save at least really 50% of cost.  It is worthwhile.

    The Features

    No distance Limitted

    No matter where you are, if the mobile phone is on line you may open the door. You may not wait for the goods carrier to send the goods later and sit at door for waiting. Upon the arrival of the goods carrier at your house, he just gives you a call, you may help him open the door immediately. It saves your precious time.

    Our product can apply to various electrical operation doors, workshop sliding doors, electric key for apartment, speedy roller shutters, traditional roller shutters and gates at the parking terminal or yards.

    One handling for many doors

    To a lot of keys, remote control devices, it takes a precious time to look for right exact key to open the door our App can operate and handle many doors, one, two, five or ten, we only use one mobile phone to cope with it. There is no trouble for taking care management of keys and remote control devices.

    Notification

    Whatever you use the mobile phone to open the door, the key or remote control device to open the door. When the door is opened by the theft once the door is open, the App will sense it. You may check the record of the user at any time. It lets the house secure.

    User managerment

    Apply to IOS and Android system, we innovated a set of safe privy calculation on the basis of QR code system, we assure it will not be disclosed by QR code management of increasing and deleting the users. To set up the apparatus, it can be completed only by the scan of QR code. To intend to increase the new user you just scan the QR code and the resident leaves, you delete it directly from the mobile phone. It is safe and easy.

    Product/

    Specification

    NS30-

    Zigbee Opener

    Input Power

    110-240V AC

    Output

    3.3V DC

    5V DC

    Application

    Barrier、Rolling door、Magnetic lock

    Plug Type

    US Specification

    EU Specification

    Internet Mode

    2.4GHz(IEEE 802.15.4 and Zigbee) Zigbee @2007

    DO

    3*NC/NO

    DI

    1

    Operating Temperature

    0-50 ℃

    Operating Humidity

    5-95RH

    Dimensions(mm)

    115*90*40

    Weight(g)



    Inter Compatibility

    IOS. Android

    Person limit

    None

    Bandwidth

    2.4~2.4835GHz

    Communication Distance

    Over 53meter (Open Area 50Meter,Indoor 10Meter,After Wall 5Meter)

    Power Consumption

     CPU 2.1W (1~0.35W)

    Mounting height of Device

    Over 0.3Meter

    Initialize time

    Over 4 Second

    ZigBee Dimmer Controller For Smart Home Automation

    ZigBee Home automation
    Place of Origin: Taiwan Taipei
    Communication Type : Zigbee 802.15
    Model number : NS30DIM
    ZIGBEE Chipset :TICC2530
    Frequency : 2.4G
    Power : 110V /220V AC
    OutPut : 110V /220V AC
    Max Load Power : 700W
    Dimmer Tech : TRAIC Control
    Dimmer Level : 0~100% 15 Level

    Abstract

    Zigbee dimmer is an important element in wireless e-home and power saving application . Our dimmer can be widely used in LED CCFL and other TRAIC compatible  dimming  lamps.

    Vector ZIGBEE Dimmer has a very low power consumption, the power consumption itself is about 0.1W. But the output loading is up 700 W , it can effectively control  the lamp in a area.

    The Application

    Application
    Vector currently offers three areas of application.

    1 Use app to control : etouch provided by the Company will be automatically true measure where you are all the LAN controller, through Etouch APP, you can easily have a very low price to achieve remote control. Currently our Etouch APP, providing door openers, alarm, power controller


    2 Parking garage area  lighting system :

    We provide a parking area lighting control system . This system will link  Micro-wave sensor ,and the lighting  dimmer  . When any  movement of people and vehicles was detected via the motion sensor ,  the lighting will be adjusted to the brightest lights in order to maintain safety. If no any motion was detected , the system will dim 20% to save the power.

    3 office lighting system :

    Office Lighting power saving system will detect the human  through infrared sensors or motion sensors. In office , it will offer brightest light when there is someone in the office.
    And if people leave the sensor detecting area , the system will dim darker to save power energy.

    The Result

    影片

    Product/

    Specification

    NS30-

    Zigbee Dimmer

    Input Power

    110-240V AC

    Output

    110-240V AC

    3.3V DC

    5V DC

    Application

    Dimmable Lamps

    Plug Type

    US Specification

    EU Specification

    Internet Mode

    2.4GHz(IEEE 802.15.4 and Zigbee) Zigbee @2007

    DO

    None

    DI

    1

    Operating Temperature

    0-50 ℃

    Operating Humidity

    5-95RH

    Dimensions(mm)

    115*90*40

    Weight(g)



    Inter Compatibility

    IOS. Android

    Person limit

    None

    Bandwidth

    2.4~2.4835GHz

    Communication Distance

    Over 53meter (Open Area 50Meter,Indoor 10Meter,After Wall 5Meter)

    Power Consumption

     CPU 2.1W (1~0.35W)

    Mounting height of Device

    Over 0.3Meter

    Initialize time

    Over 4 Second

    Overload

    700W



    News

    Our recent activities and news

    • The platform of global security manufacturing



      Leading security platform to connect original manufacturers with worldwide buyers

      Vector Technology invite you to visit the venue to see the newest results of our research.



    • Zigbee System release



      We have recently released  the following Zigbee products:

      . 1 ZIgbee light control switch: This switch is the e-Home of the most desired elements, through this element, the user can use the smartphone switch lights, and adjust the brightness of the light.

      2 Zigbee Parking saving system: This system will automatically adjust the lighting in the parking lot. For example , if  there is no  people and moving vehicles, then  the lights will be adjusted to 20% ~50% , so you can effectively save electricity.

      3 Zigbee automatic daylight balanced system: This system during the day will automatically adjust the lighting down  when sufficient daylight .and  when the light is not enough, it will automatically adjust the lighting up.

      4 zigbee door opener: To use the phone to open the door, it is amazing is not it! In addition to this application, we also increased the anti-theft feature.For  When someone enters your office at night, your phone will receive an alert message.

    About Us

    Vector Technology Corporation (VTC) is one of the leading suppliers of Telephony products in the world. Base on the experience in research and marketing of communication field for 18 years. We have completely payphone, VOIP, security and vending machine products. As well as the professional software system engineers team to provide the system integration.


    Today Vector is a Solution Provider company. We architect the solutions for our clients. We call ourselves as solution architects instead of software architects is because we provide business centric software architecting services. Being specialized in the product development, we realize the importance of having right software architecture. Software architecture is a blue-print of the software; it is a foundation of the software. Architecture defines major components, their relationships, structure, behavior and rational behind it. Vector provides solution architecting consultancy to fulfill the needs of all the stakeholders from the solution architecture. It generally includes technology platform, physical architecture, software architecture, network architecture with all functional software requirements addressed. As a designer and manufacturer, the request of customer will be fulfilled in the best way and in the shortest time. With VTC's experienced team, our engineers work to find idea solutions to meet customers' demand and make us trustworthy. We also look to expand our business to serve more customers and to provide better services . We greatly appreciate supports from the customers worldwide.These customers include some telecommunication companies owned by their countries, mobile telecommunication companies and private telecommunication companies.

    Contact Us

    Are you have any problem or any suguesstion about us?
    Visit us, write to us or call us

    Drop us a line

    Find Us

    • 8F., No.2, Lane. 122, Sec. 2, Ganyuan St., Shulin City, Taipei County 238, Taiwan
    • +886 - 2 - 2680 - 2050
    • +886 - 2 - 2680 - 2060
    • Payphone@vector.com.tw

    Business Hours

    • Mon - Fri : 9:00 am - 6:00 pm
